Description
Wayne Dalton Garage Door Bottom Brackets
Garage door bottom fixtures / bottom brackets.
1 PAIR – 1 – RH and 1 – LH Bottom Bracket.
Genuine Wayne Dalton Parts – Original Replacement part #236515 & 236214
Dimensions:
1-3/8″ Tall
3-3/4″ Wide
1″ Return flange
Millford Pin spud to attach the cable from the spring (s). Multiple mounting holes, Fasteners included.
Works with Wayne Dalton Model 5120, 5140, 6100, 9100, 9400, 9600, 9700
And many other garage doors.
Wayne Dalton has a “Pinch Proof” hinge that it uses on some of its garage doors and you can find those here – WAYNE DALTON GARAGE DOOR HINGE
This is the bracket that the cable is attached to in the lower corner of the garage door. These bottom brackets also act as the bottom roller holder.
CAUTION – THIS BRACKET IS UNDER EXTREME TENSION – ALL SPRING TENSION MUST BE REMOVED BEFORE REMOVING OR WORKING ON THESE BOTTOM BRACKETS.
We stock other bottom brackets for applications other than these specific Wayne Dalton brackets, click this link to see other options – GARAGE DOOR BOTTOM BRACKETS
Another option to consider is one of our garage door tune up kits. We have various kits for all residential sized garage doors that replace the hinges, rollers and other parts as well. We have Basic, Standard and Deluxe kits as well as quiet kits that utilize nylon reinforced hinges and heavy duty nylon 13 ball bearing rolls that will quiet any garage door to an incredible degree. Click this link to check out our garage door hardware kits – GARAGE DOOR HARDWARE KIT
If you do decide to replace more than just the bottom brackets and do not find a kit that suites your needs, send us an email with a list of what you do need and we will provide a quote.
